Specifications

---



Product Glance	Value
Model	L11
Algorithm | Cryptocurrency	Scrypt | LTC+DOGE+BEL+JKC+LKY+PEP
Typical Hashrate, GH/s(1-1)	20
Power on wall @25°C, Watt(1-1).	3680
Power efficiency on wall@25°C(1-2), J/GH(1-1)	184

Detailed Characteristics	Value
Power supply
Phase	1
Input voltage, Volt(2-1)	220~277
Input Frequency Range, Hz	50/60
Input max current(2-2), Amp	20
Power Port	P14
Hardware Configuration
Network connection mode	RJ45 Ethernet 10/100M
Server size (Length*Width*Height, w/o package), mm	468*219*293
Server size (Length*Width*Height, with package), mm	630*350*430
Net weight, kg	19.2
Gross weight, kg	22.2
Noise(2-3) @25℃, dBA	76
Max airflow(2-4), CFM	480
Environment Requirements
Operating temperature, °C	-20~45
Storage temperature, °C	-40~70
Operation humidity(non-condensing), RH	10~90%
Operating altitude(2-5), m	≤2000

  Notes: (1-1) The hashrate value, power on wall, and power efficiency on wall are all typical values. The actual hashrate value fluctuates by ±3%, and the actual power on wall and power efficiency on wall fluctuate by ±5%. (1-2) Inlet air temperature. (2-1) Caution: Wrong input voltage may probably cause server damaged. (2-2) Single-phase AC input 20A. (2-3) Max condition: Fan is under max RPM(rotation per minute). (2-4) When the server is dusty or the environment is poorly ventilated, the server airflow will reduce. (2-5) When the server is used at an altitude from 900m to 2000m, the highest operating temperature decreases by 1℃ for every increase of 300m.
