Specifications

---



Product Glance	Value
Model	L9
Algorithm | Cryptocurrency	Scrypt | LTC+DOGE+BEL
Typical Hashrate, GH/s(1-1)	16
Power on wall @25°C, Watt(1-1).	3360
Power efficiency on wall@25°C, J/GH(1-1)	210

Detailed Characteristics	Value
Single-Phase AC Power supply
Input voltage, Volt(2-1)	220~277V
Input Frequency Range, Hz	50~60
Input max current, Amp	20
Hardware Configuration
Network connection mode	RJ45 Ethernet 10/100M
Server size (Length*Width*Height, w/o package), mm	400*195*290
Server size (Length*Width*Height, with package), mm	570*316*430
Net weight, kg	14.2
Gross weight, kg	16.3
Noise@25℃, dBA @25℃ (2-2)	75
Environment Requirements
Operation temperature, °C	-20~45
Storage temperature, °C	-40~70
Operation humidity(non-condensing), RH	10~90%
Operation altitude, m(2-3)	≤2000

Notes: (1-1) The Hashrate value, Power on wall, and Power efficiency on wall are all typical values. The actual Hashrate value fluctuates by ±3%, and the actual Power on wall and Power efficiency on wall fluctuate by ±5%. (2-1) Caution: Wrong input voltage may cause server damaged. (2-2) Max condition: Fan is under max RPM (rotation per minute). (2-3) When the miner is used at an altitude from 900m to 2000m, the highest operating temperature decreases by 1℃ for every increase of 300m.
