| Specifications

---



Product Glance	Value
Model	S19j XP
Version	K1-20
Algorithm | Cryptocurrency	SHA256 | BTC/BCH/BSV
Hashrate, TH/s	151
Power on wall @25°C, Watt	3247 ±10%
Power efficiency on wall @25°C, J/TH	21.5 ±5%

Detailed Characteristics	Value
Power supply
Power supply AC input voltage, Volt(1-1)	220~277
Power supply AC input frequency range, Hz	47~63
Power supply AC input current, Amp(1-2)	20(1-3)
Hardware configuration
Network connection mode	RJ45 Ethernet 10/100M
Miner size (length*width*height, w/o package), mm(2-1)	400*195*290
Miner size (length*width*height, with package), mm	570*316*430
Net weight, kg(2-2)	14.9
Gross weight, kg(2-2)	16.5
Environment requirements
Operation temperature, °C	0~40
Storage temperature, °C	-20~70
Operation humidity(non-condensing) , RH	10%~90%
Operation altitude, m(3-1)	≤2000

Notes: 1. To prevent the spread of virus in the firmware, which can cause damage to the ANTMINER S19 series, the setting function of “Secure Boot” has been switched on and the “Root Authority” function has been disabled. 2. If the user fails to use the product in accordance with the given instructions, specifications, and conditions provided, or change the function setting without BITMAIN's prior consent, BITMAIN will not be liable for any damage arising therefrom. (1-1) Caution: Wrong input voltage may probably cause miner damaged (1-2) Max condition: temperature 40°C, altitude 0m (1-3) Two AC input wires, 10A per wire (2-1) ​​​​Including PSU size (2-2) Including PSU weight
