| Specifications

---



Product Glance	Value
Model	X5
Algorithm | Cryptocurrency	RandomX | XMR
Hashrate, KH/s	212 ±3%
Power on wall @25°C, Watt	1350 ±10%
Power efficiency on wall @25°C, J/KH	6.37 ±10%

Detailed Characteristics	Value
Power supply
Power supply AC input voltage, Volt(1-1)	200~240
Power supply AC input frequency range, Hz	47~63
Power supply AC input current, Amp(1-2)	20(1-3)
Hardware configuration
Networking connection mode	RJ45 Ethernet 10/100M
Miner size (length*width*height, w/o package), mm(2-1)	428*195*290
Miner size (length*width*height, with package), mm	597*317*427
Net weight, kg(2-2)	16.95
Gross weight, kg	18.8
Environment requirements
Operation temperature, °C	0~40
Storage temperature, °C	-20~70
Operation humidity(non-condensing) , RH	10~90%
Operation altitude, m(3-1)	≤2000

Notes: 1. If the user fails to use the product in accordance with the given instructions, specifications, and conditions provided, or change the function setting without BITMAIN's prior consent, BITMAIN will not be liable for any damage arising therefrom. (1-1) Caution: Wrong input voltage may probably cause miner damaged (1-2) Max condition: temperature 40°C, altitude 0m (2-1) ​​​​Including PSU size (2-2) Including PSU weight (3-1) When the miner is used at an altitude from 900m to 2000m, the highest operating temperature decreases by 1℃ for every increase of 300m.
